16 Ton SHACMAN Truck Mounted Crane JQCM 5 Section U Boom Hydraulic Lifting Transport Vehicle Export

Name: 16 Ton SHACMAN Truck Mounted Crane JQCM 5 Section U Boom Hydraulic Lifting Transport Vehicle Export
Brand: جلوبال ماتشكس
Availability: InStock
Rating: 5 (1 reviews)

JQCM 16-ton 6×4 truck mounted crane on SHACMAN chassis, equipped with Weichai 350HP diesel engine and Fast 9-speed gearbox. 5-section U-type synchronous telescopic boom with max lifting torque 40000kg·m, 360° full slewing operation. Double-layer thickened frame and automatic 2-section hydraulic outriggers, dual function for cargo transport and lifting, rated truck loading capacity 8720kg. Suitable for heavy steel, seedling and construction material lifting & haulage. Single unit or full container bulk export available with one-stop customs, inspection & certificate of origin service.

$0.15 - 148148.00

إرسال رسالة اتصل بالمورد

Jining Jiaqing Special Vehicle (Group) Co., Ltd.

عرض المورد

Year Established Established in 2015

Employees 101-500 People

Factory Area 10,000-50,000 m²

Annual Revenue US$10 Million - US$50 Million

Main Markets Southeast Asia / Middle East & North Africa

التفاصيل

المواصفات

معلومات التجارة

SHACMAN 6×4 heavy-duty 3-layer frame chassis, stable for long-distance heavy haulage
Original SHACMAN 6×4 rear eight-wheel chassis with 300mm triple thickened main beam for high rigidity. Matched Weichai 350HP engine and Fast 9-speed gearbox, 1200R20 heavy steel tires, full load gross weight up to 31 tons. Resist beam deformation during long-distance steel & large material transport, sufficient torque for mountain climbing with full load.
5-section high-strength U boom, 16-ton high torque for multi-scene lifting
Integrated 5-section thick U boom with max lifting height 22.8m and max torque 40t·m. The 2nd boom section supports independent extension to adjust working radius. Wear-resistant anti-bending boom steel, 360° unlimited full slewing, stable operation for steel structure factory installation, seedling transplant and sand equipment hoisting.
Automatic 2-stage hydraulic outriggers, fast leveling & anti-rollover
Fully automatic 2-section telescopic hydraulic legs with 2.5m transverse and 5.8m longitudinal working span, synchronous extension for quick single-leg leveling on uneven construction ground. Built-in hydraulic lock seals oil circuit during operation to eliminate risks of leg collapse and vehicle rollover, complying with international construction safety standards.
Dual cargo & lifting integrated design, lower procurement cost
Integrated factory cargo box + truck crane design with rated cargo capacity 8720kg, finish both material haulage and on-site lifting with one single vehicle, no need to purchase separate truck and crane. Ideal for steel dealers, garden contractors and infrastructure builders, cutting equipment investment and transfer labor cost.
Integrated full hydraulic control system, easy operation & low failure rate
Centralized hydraulic control for boom extension, slewing, luffing and outrigger movements, neat pipeline layout with stable heat dissipation. 360° unrestricted rotation enables flexible operation on narrow rural and compact construction sites. Universal spare parts simplify overseas maintenance.
One-stop full export supporting service
①Original technical data booklet, factory lifting performance test report, dual-language operation & maintenance manual delivered with each unit;
②Whole vehicle rust removal & cleaning, anti-rust wrapping for boom and outriggers, two sea shipment packaging options: full container or bulk vessel;
③Full wearable spare parts including hydraulic motor, winch, oil seals and steel wire rope can be consolidated in container for supplementary export;
④One-stop service for construction machinery customs declaration, certificate of origin and equipment inspection official documents.

Rated Lifting Capacity

16000kg (16 Ton)

Chassis Model

SHACMAN 6×4 Heavy-duty Chassis

Overall Dimension

1200025503980mm

Wheelbase

3500+4575mm

Full Load Gross Weight

31000kg

Crane Curb Weight

22150kg

Rated Cargo Loading

8720kg

Engine

Weichai 350HP / 257kW Diesel Engine

Transmission

Fast 9-speed Manual Gearbox

Max Travel Speed

90km/h

Tire Spec

1200R20-18PR Heavy Steel Wire Tires

Frame

300mm 3-layer Thickened Frame

Boom Structure

5-section U-type Telescopic Boom, 5.8~19.8m

Max Lifting Height

22.8m

Max Lifting Torque

40000kg·m

Extension Mode

Independent Operation For 2nd Boom Section

Slewing Angle

360° Full Unlimited Rotation

Boom Elevation Angle

0~80°

Outrigger Type

Automatic 2-section Hydraulic Telescopic Legs

Working Span

Transverse 2.5m / Longitudinal 5.8m

الحد الأدنى لكمية الطلب

1 قطع

وصف

SHACMAN 6×4 heavy-duty 3-layer frame chassis, stable for long-distance heavy haulage
Original SHACMAN 6×4 rear eight-wheel chassis with 300mm triple thickened main beam for high rigidity. Matched Weichai 350HP engine and Fast 9-speed gearbox, 1200R20 heavy steel tires, full load gross weight up to 31 tons. Resist beam deformation during long-distance steel & large material transport, sufficient torque for mountain climbing with full load.
5-section high-strength U boom, 16-ton high torque for multi-scene lifting
Integrated 5-section thick U boom with max lifting height 22.8m and max torque 40t·m. The 2nd boom section supports independent extension to adjust working radius. Wear-resistant anti-bending boom steel, 360° unlimited full slewing, stable operation for steel structure factory installation, seedling transplant and sand equipment hoisting.
Automatic 2-stage hydraulic outriggers, fast leveling & anti-rollover
Fully automatic 2-section telescopic hydraulic legs with 2.5m transverse and 5.8m longitudinal working span, synchronous extension for quick single-leg leveling on uneven construction ground. Built-in hydraulic lock seals oil circuit during operation to eliminate risks of leg collapse and vehicle rollover, complying with international construction safety standards.
Dual cargo & lifting integrated design, lower procurement cost
Integrated factory cargo box + truck crane design with rated cargo capacity 8720kg, finish both material haulage and on-site lifting with one single vehicle, no need to purchase separate truck and crane. Ideal for steel dealers, garden contractors and infrastructure builders, cutting equipment investment and transfer labor cost.
Integrated full hydraulic control system, easy operation & low failure rate
Centralized hydraulic control for boom extension, slewing, luffing and outrigger movements, neat pipeline layout with stable heat dissipation. 360° unrestricted rotation enables flexible operation on narrow rural and compact construction sites. Universal spare parts simplify overseas maintenance.
One-stop full export supporting service
①Original technical data booklet, factory lifting performance test report, dual-language operation & maintenance manual delivered with each unit;
②Whole vehicle rust removal & cleaning, anti-rust wrapping for boom and outriggers, two sea shipment packaging options: full container or bulk vessel;
③Full wearable spare parts including hydraulic motor, winch, oil seals and steel wire rope can be consolidated in container for supplementary export;
④One-stop service for construction machinery customs declaration, certificate of origin and equipment inspection official documents.
